Das Tank: CObject Class Reference

Definition at line 134 of file structs.h.


Public Member Functions
	CObject (void)
	default constructor
	CObject (int typeID, CWorld *ThisWorld)
	standard constructor
int	Draw (void)
	draw this object on the screen
void	StartAnimating (void)
	start an object's animation
void	StopAnimating (void)
	stop an object's animation
void	SetBB (float left, float right, float bottom, float top)
	set this object's bounding box
Public Attributes
CWorld *	ParentWorld
	the CWorld object that this object is part of
Vector	Position
	this object's world-coordinate position in 2D space
Vector	OldPosition
Vector	Acceleration
	this object's 2D acceleration vector
Vector	Velocity
	this object's 2D velocity vector
CObject *	Previous
	a link to the previous CObject when this object is in a linked list
CObject *	Next
	a link to the next CObject when this object is in a linked list
CObject *	Owner
	a link to another CObject which 'owns' this object
float	fBBLeft
	left edge of this object's bounding box
float	fBBRight
	right edge of this object's bounding box
float	fBBBottom
	top edge of this object's bounding box
float	fBBTop
	bottom edge of this object's bounding box
float	fDrawLeft
	left edge of this object's texture map area
float	fDrawRight
	right edge of this object's texture map area
float	fDrawBottom
	bottom edge of this object's texture map area
float	fDrawTop
	top edge of this object's texture map area
float	fAngle
	Z axis angle of this object in relation to the playfield.
float	fSubAngle
	auxilliary angle used to keep track of a tank's turret
int	iOwnCount
	the number of objects this object 'owns'
int	iType
	a type ID representing this objects type (e.g. super-bullet)
int	iHealth
	the amount of health this object has
int	iDamage
	the amount of damage this object will do when damaging another object
int	iLives
	the amount of remaining 'rest' lives the player has
int	iTint
	the tint color of this object, used to mark an object's ownership
int	iRemovalEffects
	the total number of effects to create when the object is removed
int	iRemovalEffect [8]
	the effect to put in this object's place when it's removed (health == 0)
int	iRemovalSound
	the sound to play when this object is removed
int	iDamageSound
	the sound to play when this object is damaged
bool	iInput [8]
	an array representing the objects 'input' for use with tank control
int	iTexture
	a texture ID representing the texture map that should be drawn for this object
int	iWeapon
	the weapon this player/NPC is wielding
int	iAmmo
	the number of rounds of ammunition this object is carrying (-1 == infinity)
bool	bCheckedForCollision
	a progress flag reset each time through the collision routines
bool	bDying
	object has no health, but is still playing it's outro animation
bool	bVisible
	whether or not the object should be drawn to the screen
int	iCreationAnim
int	iCreationAnimSpeed
int	iNormalAnim
int	iNormalAnimSpeed
int	iRemovalAnim
int	iRemovalAnimSpeed
Uint32	iAnimSpeed [3]
bool	bAnimCycle
bool	bAnimating
int	iCurrentFrame
Uint32	iAnimTimeStamp
int	iLingerTime
Protected Attributes
CGeometry *	Geometry
	a pointer to the geometry used to represent this object
CEffect *	Effects
	a pointer to the effects that are attached to this object

Constructor & Destructor Documentation

CObject::CObject ( void )

Create a CObject class object with default parameters.

Definition at line 674 of file structs.cpp.

CObject::CObject	(	int	typeID,
		CWorld *	ThisWorld
	)

Creates a CWorld class object, specifying the objects type via the iType member, and the world to which this object will belong using the ParentWorld member.

Definition at line 741 of file structs.cpp.

References ANIM_CYCLE_CYCLE, ANIMID_NULL, bAnimating, bAnimCycle, bCheckedForCollision, bDying, bVisible, DEFAULT_ANGLE, DEFAULT_BB_BOTTOM, DEFAULT_BB_LEFT, DEFAULT_BB_RIGHT, DEFAULT_BB_TOP, DEFAULT_DAMAGE, DEFAULT_DRAW_BOTTOM, DEFAULT_DRAW_LEFT, DEFAULT_DRAW_RIGHT, DEFAULT_DRAW_TOP, DEFAULT_HEALTH, DEFAULT_LINGER_TIME, DEFAULT_LIVES, DEFAULT_SUB_ANGLE, Effects, fAngle, fBBBottom, fBBLeft, fBBRight, fBBTop, fDrawBottom, fDrawLeft, fDrawRight, fDrawTop, fSubAngle, Geometry, iAmmo, iAnimTimeStamp, iCreationAnim, iCreationAnimSpeed, iCurrentFrame, iDamage, iDamageSound, iHealth, iInput, iLingerTime, iLives, iNormalAnim, iNormalAnimSpeed, iOwnCount, iRemovalAnim, iRemovalAnimSpeed, iRemovalEffects, iRemovalSound, iTexture, iTint, iType, iWeapon, Next, Owner, ParentWorld, Previous, SOUNDID_NULL, TEXID_BOUNCY_SHOT, TEXID_CRATE, TEXID_HEAT_SEEKER, TEXID_LAND_MINE, TEXID_NULL, TEXID_PEA_SHOT, TEXID_POWERUP_BS, TEXID_POWERUP_HEALTH, TEXID_POWERUP_HS, TEXID_POWERUP_LM, TEXID_POWERUP_PS, TEXID_POWERUP_SB, TEXID_SUPER_BULLET, TEXID_TANK, TEXID_TNT_BLOCK, TEXID_WALL_BLOCK, TINTID_NULL, TYPEID_BOUNCY_SHOT, TYPEID_HEAT_SEEKER, TYPEID_LAND_MINE, TYPEID_PEA_SHOT, TYPEID_POWERUP_BS, TYPEID_POWERUP_HEALTH, TYPEID_POWERUP_HS, TYPEID_POWERUP_LM, TYPEID_POWERUP_PS, TYPEID_POWERUP_SB, TYPEID_SUPER_BULLET, TYPEID_TANK, TYPEID_TNT_BLOCK, TYPEID_WALL_BLOCK, TYPEID_WOOD_BLOCK, WEAPONID_NULL, and WEAPONID_PEA_SHOT.

Member Function Documentation

int CObject::Draw ( void )

Draw this object on the screen, based on the object's member data. If enabled, draw a bounding box around the object to help visualize the boundary used for collision-detection.

Definition at line 928 of file structs.cpp.

References ANIMID_CRATECRUSH, bAnimating, DRAW_BOUNDING_BOXES, fAngle, fBBBottom, fBBLeft, fBBRight, fBBTop, fDrawBottom, fDrawLeft, fDrawRight, fDrawTop, GetFrame(), GetTexture(), iCurrentFrame, iTint, Position, TINTID_ARMYBROWN, TINTID_ARMYGREEN, TINTID_BLUE, TINTID_GREEN, TINTID_NULL, TINTID_ORANGE, TINTID_PURPLE, TINTID_RED, TINTID_YELLOW, Vector::x, and Vector::y.

Referenced by DrawObjects().

Here is the call graph for this function:

Here is the caller graph for this function:

void CObject::StartAnimating ( void )

Set the object's animation flag so that the animation routines update this object, advancing it's frame based on the objects delay variable. The drawing routines will now draw this object's current animation frame.

Definition at line 1011 of file structs.cpp.

References bAnimating, iAnimTimeStamp, iCurrentFrame, CWorld::iCurrentTime, and ParentWorld.

void CObject::StopAnimating ( void )

Set the object's animation flag so that the animation routines ignore this object. The drawing routines will now draw this object's normal texture.

Definition at line 1024 of file structs.cpp.

References bAnimating.

void CObject::SetBB	(	float	left,
		float	right,
		float	bottom,
		float	top
	)

The parameters passed to this function represent lines defining the extents of the bounding box surrounding this object. For example, the fBBTop member defines the y-coordinate of the line defining the top of this objects bounding box.

Definition at line 1037 of file structs.cpp.

References fBBBottom, fBBLeft, fBBRight, and fBBTop.

Member Data Documentation
